You may delete all targets or risk areas at once by clicking on Delete
All.
4+
•
Free rotation allows you to show the real orientation of the probe
•
Set initial position allows you to set the initial position of the
probe yourself
•
View from below allows you to view the probe model from below
and could be used to verify the position of either the VirtuTRAX™ or
eTRAX™ devices
%#*
If they are correctly connected, click on either eTRAX™ On/Off or
VirtuTRAX™ On/Off to activate one of the devices.
(2
There are 2 methods for the VirtuTRAX™ calibration in the Settings
Menu, under Other Settings tab:
• Manual method
A popup window will appear asking you to manually enter the needle
distance, which is the distance between the needle tip and the bottom
part of the needle holder
• Pivot method
Do a pivot movement with the VirtuTRAX™ needle holder by putting
the needle tip on a sterile and rigid plane surface.
Follow the on-screen instructions to perform the pivot calibration.
