SuperTek SteamTek 3 - Assembly Instructions; Step-by-Step Assembly Guide

4
1. Lift up the Hand-held Steamer lock (11)
(Illust.1) then push the Hand-Held
Steamer release tab (12) up. (Illust. 2)
to detach the Hand-Held Steamer (7)
from the mop body (8).
2. Attach Mop Head (3) to Mop Body (8)
by inserting the Swivel Joint (13) into
the hole in the Mop Body. (Illust. 3)
Illust.1
Illust.2
Illust.3
Illust.4
Illust.7
Illust.8
ASSEMBLY:
Illust.6
Illust.5
3. Fix the Screw (9) on the Mop
Head with a Philips screwdriver
until tight. (Illust.4)
4. Re-attach the Hand-Held
Steamer (7) to the Mop Body (8)
and lock into place with the
Hand-held Steamer Lock. (11)
(Illust. 5 & 6).
5. Slide the Mop Handle (4) into the Mop Body (8)
until it clicks into place. (Illust 7)
NOTE: To remove the Handle (4) from the Body (8), press the button and pull handle up.
(Illust. 8).
