Chapter 2 InstallationChapter 2 Installation
The instrument into the mounting hole and then buckle on the Snap, as shown
below
2.2 Electrode installation
Schematic diagram of common installation method
①Side wall installation ②Flange mounted at the top ③Pipe installation ④Top
installation ⑤Submersible installation ⑥Flow-through installation
The interface must be in 15°oblique angle, or it will affect the normal test and use
of the electrode. We won’t be responsible for any results due to this.
