Supra 148C - Technical Characteristics and Dimensions

GB 3/16
25254-11-08
1. TECHNICAL
1. TECHNICAL
CHARACTERISTICS
CHARACTERISTICS
AND DIMENSIONS
AND DIMENSIONS
(1)
Nominal power in operation with the door closed, fuel wood or lignite; in tests according to EN 13240.
Fire place 148C 150C 152C 162C 168C 163 VL
Classification of the fire Continuous Continuous Continuous Intermittent Intermittent Intermittent
Rated power output
(1)
13 kW 13 kW 13 kW 11 kW 11 kW 11 kW
Operation door closed/open yes/no yes/no yes/no yes/yes yes/yes yes/yes
Average temperature of smoke 380°C 380°C 380°C 314°C 314°C 314°C
Efficiency 71% 71% 71% 70,4% 70,4% 70,4%
CO rate (13% O
2
) 0,46% 0,46% 0,46% 0,21% 0,21% 0,21%
Fuel: wood logs; replacement fuel : lignite
Max.log size 50 cm 50 cm 50 cm 50 cm 50 cm 50 cm
Nominal hourly load 4 kg 4 kg 4 kg 4 kg 4 kg 4 kg
Prohibited fuels: all others including coal and derivatives
Dimensions
HxLxP (mm) 750x760x518 1084x760x518 1618x760x518 1618x760x518 1326x760x518 1620x760x518
Connection type vertical vertical vertical vertical vertical vertical
Distance rear-flue axis 165 mm 170 mm 170 mm 220 mm 220 mm 220 mm
Ø of smoke outlet 200 mm 200 mm 200 mm 200 mm 200 mm 200 mm
Charactéristics of the smoke flue
Min. chimney block 20x20 cm 20x20 cm 20x20 cm 20x20 cm 20x20 cm 20x20cm
Tubing or metal flue min. Ø 180 mm 180 mm 180 mm 180 mm 180 mm 180 mm
Min. height of flue above fire 4 m 4 m 4 m 4 m 4 m 4 m
Ventilation of the room 1 dm² 1 dm² 1 dm² 1 dm² 1 dm² 1 dm²
Draught (10 Pa = 1 mm water column)
Nominal speed 12 Pa±2 12 Pa±2 12 Pa±2 12 Pa±2 12 Pa±2 12 Pa±2
Reduced speed 6 Pa±1 6 Pa±1 6 Pa±1 6 Pa±1 6 Pa±1 6 Pa±1
Max. admissible 20 Pa 20 Pa 20 Pa 20 Pa 20 Pa 20 Pa
Weight netto / brutto 115/132 kg 128/145 kg 133/152 kg 147/170 kg 138/155 kg 180/197 kg
Manufacturer's plate in the ashbox
Cool handle + bag of screws no no no no no to be mounted
Options supplied
Stand no to be mounted to be mounted to be mounted no to be mounted
Fairing no yes yes yes no yes
Fairing cover no no yes yes no mounted
Warm air nozzles no no to be mounted to be mounted no to be mounted
Plugs no no to be mounted to be mounted no to be mounted
1 Cast iron side no no no no no to be mounted
1 Side cover no no no no no to be mounted
Cool handle + bag of screws no no no no no to be mounted
Options available
CDA 150C --- yes --- -- --- ---
CDA 168C --- --- --- --- yes ---
DA 168C --- --- --- yes --- ---
KTE152 ventilation kit yes yes yes yes yes yes
Kit grill yes yes yes yes yes yes
