Fuse Panel - Top of Engine
Main Dash Power-Circuit Breaker - Battery Connection
The power to the dash circuit is protected by a circuit breaker that is located in the
observer seat storage area near the battery.
To turn o the power to the dash, manually press the red button and the circuit breaker
reset lever will ip down and the power to the dash circuit will be shut o. To reset the
breaker, push the reset lever back up.
If all of the dash switches fail to work, reset the main dash power-circuit breaker.
Main Ballast Power-Circuit Breaker - Battery Connection
The power to the ballast pump circuit is protected by a circuit breaker that is located in
the engine compartment.
To turn o the power to the ballast pump, manually press the red button and the circuit
breaker reset lever will ip down and the power to the ballast circuit will be shut o. To
reset the breaker, push the reset lever back up.
The Power Distribution Module (PDM) has an internal circuit protection for the Vision system
and other components controlled through the Vision system. There are three PDM’s in the
2017 Supra models; two under the dash that controls the forward components on the Vision
system. The third PDM is located on the transom and controls the ballast, wake plate, and
underwater lights.
The power to each PDM is protected by its own circuit breaker. The
dash PDM has a breaker also under the dash. The circuit breaker for the
transom PDM is located inside the engine compartment.
To turn o the power to the PDM’s, manually press the red button and the circuit breaker
reset lever will ip down and the power to the PDM’s will be shut o. To reset the circuit
breaker, push the reset lever back up.
PDM Breaker
