FCC Statement
This equipment can generate, use and radiate radio frequency energy and, if not
installed and used in accordance with the instructions in this manual, may cause
interference to radio communications. This equipment has been tested and found to
comply with the limits for a Class A computing device pursuant to Part 15 of the FCC
rules, which are designed to provid reasonable protection against radio interference
when operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user, at his own
expense, will be required to take whatever measures are necessary to correct the
interference.
CE Declaration of Conformity
This is a Class A product. In a domestic environment product may cause radio
interference in which case the user may be required to take adequate measures.
Trademarks
All other brands and product names may be registered trademarks or trademarks of
their respective holders.
Table of Contents
Chapter 1 Introduction
Performance Hightlights
Key Features
Package Contents
Chapter 2 Hardware
Front Panel
LED Indicators
Rear Panel
Chapter 3 Network Connections
Switch to PC
Switch to Hub
Hub without Uplink (MDI) Port
Switch to Switch (Other Devices)
Chapter 4 Console Management Setup
Getting Started
Console Program
Hyper Terminal Setup
Chapter 5 The Smart Switch Setup
Getting Started
Using the System Configuration Program
Trunk/VLAN Setting Configuration
Port Status
Port Setting Configuration
Factory Default
Save Setting
Appendix A Technical Specifications
Appendix B Cable Requirements
1-1
1-2
1-3
1-3
2-1
2-1
2-2
2-3
3-1
3-1
3-2
3-3
3-4
4-1
4-1
4-1
4-2
5-1
5-1
5-1
5-3
5-4
5-5
5-6
5-6
A-1
B-1
