Stepping Systems User Manual
1–3
Chapter 1: Getting Started
5th Ed., Rev. B 01/2019
SureStep™ System Introduction
SureStep open-loop and inclusive position verification (semi-closed loop) stepping
systems provide simple and accurate control of position and speed where lower
power and cost are considerations. The SureStep family of stepping components
includes power supplies, drives, motors, and cables. The AutomationDirect
family of PLCs or other indexers and motion controllers can be used to provide
the signals that are “translated” by the microstepping drives into precise
movement of the stepping motor shaft.
SureStep™ Part Number Explanation
Drives
STP-DRV- 6575
Component Capacity
2-digit max nominal voltage followed by
max current with 1 implied decimal place
4035: 40V, 3.5 A
4850: 48V, 5.0 A
6575: 65V, 7.5 A
80100: 80V, 10.0 A
Component Type
DRV: stepper drive
DRVA: drive accessory
SureStep Series Designation: STP
Motors
STP-MTRx-23079 x
Component Capacity
2-digit NEMA frame size followed by
approximate stack* length in mm
Component Type
MTRL: low-power stepper motor
MTR: high-power stepper motor
MTRH: higher-power stepper motor
MTRA: motor accessory
SureStep Series Designation:
STP
Motor Shaft Type/Variant
blank: single shaft
D: dual shaft
E: encoder pre-mounted
W: IP65 (washdown)
*
The length of the motor that produces torque
