SureStep
TM
Stepping Systems User Manual
1–5
Chapter 1: Getting Started
5th Ed., Rev. B 01/2019
SureStep™ System Recommended Component Compatibility
SureStep Power Supply / Drive Compatibility
Drive
(1)(2)
Recommended Linear Power Supply
(1)(2)(3)
Model Number
STP-PWR
-3024
STP-PWR
-4805
STP-PWR
-4810
STP-PWR
-7005
(3)
STP-DRV-4035
12-32 VDC input (40V max)
√
No No No
STP-DRV-4850
24-48 VDC input (48V max)
√ √ √
No
STP-DRV-6575
24-65 VDC input (65V max)
√ √ √
No
STP-DRV-80100
24-80 VDC input (80V max)
√ √ √ √
STP-MTRD-17
12-48 VDC input
√ √ √
No
STP-MTRD-23, -24
12-70 VDC input
√ √ √ √
1) Do NOT use a power supply that exceeds the drive’s input voltage range. If using a non-STP linear
power supply, ensure that the unloaded voltage does not oat above the drive’s maximum input
range.
2) For best performance, use the lowest voltage power supply that supplies the required speed and
torque.
3) An unloaded STP-PWR-7005 can oat above the allowable input voltages of some drives if it is fed
with a high AC input voltage (greater than 120VAC).
SureStep Power Supply / Drive Compatibility
Drive
(1)(2)
Recommended Switching Power Supply
(1)(2)
Model Number PSB12-xxxS PSB24-xxxS PSB48-xxxS
STP-DRV-4035
12-32 VDC input (40V max)
√ √
No
STP-DRV-4850
24-48 VDC input (48V max)
No
√ √
STP-DRV-6575
24-65 VDC input (65V max)
No
√ √
STP-DRV-80100
24-80 VDC input (80V max)
No
√ √
STP-MTRD-17
12-48 VDC input
√ √ √
STP-MTRD-23, -24
12-70 VDC input
√ √ √
1) Do NOT use a power supply that exceeds the drive’s input voltage range.
2) For best performance, use the lowest voltage power supply that supplies the required speed and
torque.
