13
Ref. Part No. Description Req.
01 PDN-JDP-1301 Base Bench Model 1
01 PDN-JDP-13F01 Base Floor Model 1
02 PDN-JDP-1302 Washer 4
03 PDN-JDP-1303 Bolt 4
04 PDN-JDP-13F04 Base Flange Floor Model 1
04 PDN-JDP-1304 Base Flange 1
05 PDN-JDP-1305 Set Screw 1
06 PDN-JDP-1306 Table Height Adjustable Handle 1
07 PDN-JDP-1307 Table Bracket 1
7-1 PDN-JDP-137-1 Scale 1
08 PDN-JDP-1308 Gear Shaft 1
09 PDN-JDP-1309 Gear 1
10 PDN-JDP-1310 Worm 1
11 PDN-JDP-1311 Clamp Blot 1
12 PDN-JDP-1312 Table Arm 1
12-1 PDN-JDP-1312-1 Zero Mark 1
13 PDN-JDP-1313 Set Screw 1
14 PDN-JDP-1314 Clamp Blot 1
15 PDN-JDP-1315 Washer 1
16 PDN-JDP-1316 Bolt 1
17 PDN-JDP-1317 Table 1
18 PDN-JDP-13F18 Rack Floor Model 1
18 PDN-JDP-1318 Rack 1
19 PDN-JDP-1319 Column 1
19 PDN-JDP-13F19 Column Floor Model 1
20 PDN-JDP-1320 Screw 1
21 PDN-JDP-1321 Rack Collar 1
22 PDN-JDP-1322 Feed Handle 3
23 PDN-JDP-1323 Handle Knob 3
24 PDN-JDP-1324 Pinion Shaft 1
25 PDN-JDP-1325 Scale Sleeve 1
26 PDN-JDP-1326 Head 1
26-1 PDN-JDP-1326-1 Set Screw 2
26-2 PDN-JDP-1326-2 Rubber Bushing 1
27 PDN-JDP-1327 Set Screw 2
28 PDN-JDP-1328 Belt Tension Adjustable Rod 1
28-1 PDN-JDP-1328-1 Spring 1
29 PDN-JDP-1329 Screw 4
30 PDN-JDP-1330 Screw 2
31 PDN-JDP-1331 Lamp Frame 1
32 PDN-JDP-1332 Lamp Holder 1
32-1 PDN-JDP-1332-1 Nut 1
33 PDN-JDP-1333 Nut 1
34 PDN-JDP-1334 Spring and Cap 1
35 PDN-JDP-1335 Switch Box 1
35-1 PDN-JDP-1335-1 Washer Pad 1
35-2 PDN-JDP-1335-2 Switch Mounting Plate 1
36 PDN-JDP-1336 Screw 3
37 PDN-JDP-1337 Lamp Switch 1
Ref. Part No. Description Req.
38 PDN-JDP-1338 Power Switch 1
39 PDN-JDP-1339 Screw 3
40 PDN-JDP-1340 Power Cord 1
40-1 PDN-JDP-1340-1 Motor Cord 1
41 PDN-JDP-1341 Snap Ring 2
42 PDN-JDP-1342 Driver Sleeve 1
43 PDN-JDP-1343 Ball Bearing 2
44 PDN-JDP-1344 Snap Ring 1
45 PDN-JDP-1345 Ball Bearing 1
46 PDN-JDP-1346 Rubber Gasket 1
47 PDN-JDP-1347 Quill 1
48 PDN-JDP-1348 Ball Bearing 1
49 PDN-JDP-1349 Depth Gauge Holder 1
49-1 PDN-JDP-1349-1 Nut 1
50 PDN-JDP-1350 Screw 1
51 PDN-JDP-1351 Spindle 1
52 PDN-JDP-1352 Punch 1
53 PDN-JDP-1353 Arbor 1
54 PDN-JDP-1354 Chuck 1
55 PDN-JDP-1355 Key 1
56 PDN-JDP-1356 Bolt 2
57 PDN-JDP-1357 Motor 1
58 PDN-JDP-1358 Screw 2
59 PDN-JDP-1359 Capacitor Holder 1
60 PDN-JDP-1360 Capacitor 1
61 PDN-JDP-1361 Pulley Guard 1
62 PDN-JDP-1362 Motor Pulley 1
63 PDN-JDP-1363 Set Screw 1
64 PDN-JDP-1364 Snap Ring 1
65 PDN-JDP-1365 Ball Bearing 1
66 PDN-JDP-1366 Snap Ring 1
67 PDN-JDP-1367 Middle Pulley 1
68 PDN-JDP-1368 V-Belt 1
69 PDN-JDP-1369 V-Belt 1
70 PDN-JDP-1370 Knob 1
71 PDN-JDP-1371 Screw 1
72 PDN-JDP-1372 Middle Pulley Frame 1
73 PDN-JDP-1373 Nut 1
74 PDN-JDP-1374 Spindle Pulley 1
75 PDN-JDP-1375 Screw 1
76 PDN-JDP-1376 Cord Fixer 1
77 PDN-JDP-1377 Cord Clamp 2
78 PDN-JDP-1378 Screw 1
79 PDN-JDP-1379 Screw 1
81 PDN-JDP-1381 Washer 1
82 PDN-JDP-1382 Nut 1
83 PDN-JDP-1383 Set Screw 1
84 PDN-JDP-1384 Depth Stick Rod 1
85 PDN-JDP-1385 Nut 2
Ordering Replacement Parts
Replacement parts may be ordered from your local distributor or
directly from SureWerx. When ordering replacement parts always
provide the following information:
1. The model number and serial number of the machine.
2. The part number.
3. The part name.
4. The desired quantity of the part.
13-1/2" 3/4 HP 16 Speed Bench Drill Press & 13-1/2" 3/4 HP 16 Speed Floor Drill Press
