3
Warranty Policy
JET makes every effort to assure that its products meet high quality standards and warrants to the retail consumer/
purchaser of our products that each product is free from defects in material and workmanship. JET offers a TWO-
YEAR LIMITED WARRANTY on this product. Warranty does not apply to defects due directly or indirectly to misuse,
abuse, negligence or accidents, repairs or alterations performed outside our facilities or to a lack of maintenance.
Warranty Procedure
Any JET product for which there is a warranty claim should be returned PREPAID to an authorized JET distributor or
service centre. Authorized Warranty Depots are found at www.surewerx.com.
Specifications
Prod. No. 200225 200275 200278 200357
Mod. No. JDP-13 JDP-13F JDP-17F JDP-22F
Swing 13-1/4" 13-1/4" 17" 22"
Type Bench Floor Floor Floor
Chuck Size 1/32"-5/8" (1-16 mm) 1/32"-5/8" (1-16 mm) (5-200 mm) 3/4"
Drilling Capacity 5/8" 5/8" 5/8" 1-1/4"
Spindle Travel 3-1/16" 3-1/4" 3-3/8" 4-1/2"
Spindle Distance to Base 24" 48-3/4" 48-3/8" 49"
Spindle Distance to Table 17-1/2 " 31-1/2" 28½" 29"
Table Size 11-7/16" 11-7/16" 13-3/4" 16-1/2" x 18-3/4"
Table Tilt (R and L) 0° - 45° 0° - 45° 0° - 45° 0° - 45°
Spindle Taper JT3 JT3 JT3 MT3
Column Diameter 2-7/8" 2-7/8" 3-1/8" 3-5/8"
Number of Spindle Speeds 12 12 16 12
Range of Spindle Speeds (RPM) 280-3,000 280-3,000 220-3,380 180-4,200
Overall Height 38-1/2" 61-5/8" 64" 69-1/4"
Base size 10" x 16-1/2" 10" x 16-1/2" 12" x 19-3/4" 19-5/8" x 22-1/2"
Motor 3/4 H P, 1PH 3/4 H P, 1PH 1HP, 1PH 1. 5H P, 1P H
115/230V 115/230V 115/230V 115/230V
Prewired 115V Prewired 115V Prewired 115V * Prewired 115V *
Product Weight 94 lbs. 107 lbs. 176 lbs. 353 lbs.
Shipping Weight 99 lbs. 112 lbs. 184 lbs. 373 lbs.
Standard Equipment: Built-in work lamp, drill chuck and key, positive depth stop.
* If converting to 230V power standard switch and face plate must be replaced with item
PDN-JDP-1338 Switch and item PDN-JDP-1725 Face Plate
