15
Ref. Part No. Description Req.
01 PDN-JDP-1701 Guard Cover 1
02 PDN-JDP-1702 Pan Head Screw 1
03 PDN-JDP-1703 Knob 1
04 PDN-JDP-1704 Nut 1
05 PDN-JDP-1705 Spindle Pulley 1
06 PDN-JDP-1706 V-Belt 1
07 PDN-JDP-1707 Middle Pulley 1
08 PDN-JDP-1708 Ball Bearing 2
09 PDN-JDP-1709 Retaining Ring 1
10 PDN-JDP-1710 Motor Pulley 1
11 PDN-JDP-1711 V-Belt 1
12 PDN-JDP-1712 Set Screw 1
13 PDN-JDP-1713 Screw 2
13-1 PDN-JDP-1713-1 Washer 2
14 PDN-JDP-1714 Pulley Support Plate 1
15 PDN-JDP-1715 Screw 2
16 PDN-JDP-1716 Cord Protector 1
17 PDN-JDP-1717 Electrical Cord 1
18 PDN-JDP-1718 Pulley Insert 1
19 PDN-JDP-1719 Retaining Ring 2
20 PDN-JDP-1720 Ball Bearing 2
21 PDN-JDP-1721 Bearing Spacer 1
22 PDN-JDP-1722 Pan Head Screw 3
23 PDN-JDP-1723 Start/Stop Switch 1
24 PDN-JDP-1724 Light Switch Push Button 1
25 PDN-JDP-1725 Switch Plate 1
25-1 PDN-JDP-1725-1 Rubber 1
26 PDN-JDP-1726 Pan Head Screw 3
27 PDN-JDP-1727 Box Switch Plate 1
28 PDN-JDP-1728 Cord Clamp 1
29 PDN-JDP-1729 Bolt 1
30 PDN-JDP-1730 Hex Nut 1
31 PDN-JDP-1731 Hex Nut 1
32 PDN-JDP-1732 Tension Spring Assembly 1
33 PDN-JDP-1733 Post Depth Stop 1
34 PDN-JDP-1734 Lock Nut 2
35 PDN-JDP-1735 Cord Clamp 1
36 PDN-JDP-1736 Lock Pin 1
37 PDN-JDP-1737 Screw 1
38 PDN-JDP-1738 Head 1
39 PDN-JDP-1739 Thumb Screw 1
40 PDN-JDP-1740 Retaining Ring 1
41 PDN-JDP-1741 Adjusting Lever 1
42 PDN-JDP-1742 Lever Shaft Assembly 1
43 PDN-JDP-1743 Set Screw 2
44 PDN-JDP-1744 Retaining Ring 1
45 PDN-JDP-1745 Motor Support Bracket 1
46 PDN-JDP-1746 Motor Support Bracket 1
47 PDN-JDP-1747 Electrical Cord 1
48 PDN-JDP-1748 Strain Relief 1
Ref. Part No. Description Req.
49 PDN-JDP-1749 Spring Washer 2
50 PDN-JDP-1750 Nut 2
51 PDN-JDP-1751 Hex Head Screw 4
52 PDN-JDP-1752 Motor Mount 1
53 PDN-JDP-1753 Motor 1
54 PDN-JDP-1754 Nut 4
55 PDN-JDP-1755 Rubber 1
56 PDN-JDP-1756 Junction Box 1
57 PDN-JDP-1757 Screw 1
58 PDN-JDP-1758 Retaining Ring 1
59 PDN-JDP-1759 Ball Bearing 1
60 PDN-JDP-1760 Rubber Washer 1
61 PDN-JDP-1761 Quill 1
62 PDN-JDP-1762 Thrust Bearing 1
63 PDN-JDP-1763 Screw 1
64 PDN-JDP-1764 Clamping Seat Depth Stop 1
65 PDN-JDP-1765 Lock Nut 1
66 PDN-JDP-1766 Spindle 1
67 PDN-JDP-1767 Arbor 1
68 PDN-JDP-1768 Chuck 1
68-1 PDN-JDP-1768-1 Key 1
69 PDN-JDP-1769 Screw 2
70 PDN-JDP-1770 Lamp Bracket 1
71 PDN-JDP-1771 Spacer 1
72 PDN-JDP-1772 Pinion, Feed 1
73 PDN-JDP-1773 Knob 3
74 PDN-JDP-1774 Handle 3
75 PDN-JDP-1775 Rack Collar 1
76 PDN-JDP-1776 Set Screw 1
77 PDN-JDP-1777 Column 1
78 PDN-JDP-1778 Rack Gear 1
79 PDN-JDP-1779 Elevating Worm 1
80 PDN-JDP-1780 Gear 1
81 PDN-JDP-1781 Bolt Clamp 1
82 PDN-JDP-1782 Table Arm Bracket 1
83 PDN-JDP-1783 Gear Shaft 1
84 PDN-JDP-1784 Set Screw 1
85 PDN-JDP-1785 Sleeve and Rod Assembly 1
86 PDN-JDP-1786 Table Bracket 1
87 PDN-JDP-1787 Set Screw 1
88 PDN-JDP-1788 Table Lock Handle 1
89 PDN-JDP-1789 Washer 1
90 PDN-JDP-1790 Blot 1
91 PDN-JDP-1791 Table 1
92 PDN-JDP-1792 Flange 1
93 PDN-JDP-1793 Bolt 4
94 PDN-JDP-1794 Spring Washer 4
95 PDN-JDP-1795 Bake 1
96 PDN-JDP-1796 Drift Key 1
Ordering Replacement Parts
Replacement parts may be ordered from your local distributor or directly from SureWerx.
When ordering replacement parts always provide the following information:
1. The model number and serial number of the machine.
2. The part number.
3. The part name.
4. The desired quantity of the part.
17" 1 HP 16 Speed Floor Drill Press
