17
Ref. Part No. Description Req.
01 PDN-JDP-2201 Spindle Pulley 1
02 PDN-JDP-2202 Nut 1
03 PDN-JDP-2203 Pulley Cover 1
04 PDN-JDP-2204 Screw 1
05 PDN-JDP-2205 Knob 1
06 PDN-JDP-2206 Bearing 2
07 PDN-JDP-2207 V-Belt 1
08 PDN-JDP-2208 Middle Pulley 1
09 PDN-JDP-2209 Retaining Ring 1
10 PDN-JDP-2210 V-Belt 1
11 PDN-JDP-2211 Retaining Ring 1
12 PDN-JDP-2212 Shaft Assembly 1
13 PDN-JDP-2213 Motor Pulley 1
14 PDN-JDP-2214 Screw 1
15 PDN-JDP-2215 Strain Relief 1
16 PDN-JDP-2216 Motor Cord 1
17 PDN-JDP-2217 Cord With Plug 1
18 PDN-JDP-2218 Pulley Insert 1
19 PDN-JDP-2219 Retaining Ring 2
20 PDN-JDP-2220 Bearing Spacer 1
21 PDN-JDP-2221 Bearing 2
22 PDN-JDP-2222 Bolt 1
23 PDN-JDP-2223 Hex Nut 1
24 PDN-JDP-2224 Hex Nut 1
25 PDN-JDP-2225 Spring and Cap 1
26 PDN-JDP-2226 Washer 1
27 PDN-JDP-2227 Start/Stop Switch 1
28 PDN-JDP-2228 Screw 3
29 PDN-JDP-2229 Light Switch 1
30 PDN-JDP-2230 Switch Plate 1
31 PDN-JDP-2231 Screw 2
32 PDN-JDP-2232 Screw 3
33 PDN-JDP-2233 Switch Box 1
34 PDN-JDP-2234 Nut 1
35 PDN-JDP-2235 Clamping Seat Depth Stop 1
36 PDN-JDP-2236 Screw 1
37 PDN-JDP-2237 Post Depth Stop 1
38 PDN-JDP-2238 Lock Nut 2
39 PDN-JDP-2239 Screw 2
40 PDN-JDP-2240 Motor Bracket Support 1
41 PDN-JDP-2241 Screw 1
42 PDN-JDP-2242 Cord Clamp 1
43 PDN-JDP-2243 Motor Bracket Support 1
44 PDN-JDP-2244 Retaining Ring 1
45 PDN-JDP-2245 Wing Screw 2
46 PDN-JDP-2246 Screw 1
47 PDN-JDP-2247 Adjusting Lever 1
48 PDN-JDP-2248 Retaining Ring 1
49 PDN-JDP-2249 Lever Shaft 1
50 PDN-JDP-2250 Hex Head Screw 4
51 PDN-JDP-2251 Motor Plate 1
52 PDN-JDP-2252 Spring Washer 2
Ref. Part No. Description Req.
53 PDN-JDP-2253 Hex Nut 2
54 PDN-JDP-2254 Motor 1
55 PDN-JDP-2255 Hex Nut 4
56 PDN-JDP-2256 Rubber 1
57 PDN-JDP-2257 Junction Box 1
58 PDN-JDP-2258 Screw 4
59 PDN-JDP-2259 Screw 1
60 PDN-JDP-2260 Set Screw 2
61 PDN-JDP-2261 Pan Screw 2
62 PDN-JDP-2262 Lamp Bracket 1
63 PDN-JDP-2263 Spacer 1
64 PDN-JDP-2264 Pinion Shaft 1
65 PDN-JDP-2265 Feeding Handle 3
66 PDN-JDP-2266 Knob 3
67 PDN-JDP-2267 Spindle Nut 1
68 PDN-JDP-2268 Bearing 1
69 PDN-JDP-2269 Quill Gasket 1
70 PDN-JDP-2270 Quill 1
71 PDN-JDP-2271 Thrust Bearing 1
72 PDN-JDP-2272 Bearing 1
73 PDN-JDP-2273 Spindle 1
74 PDN-JDP-2274 Drift Key 1
75 PDN-JDP-2275 Arbor 1
76 PDN-JDP-2276 Chuck 1
76-1 PDN-JDP-2276-1 Key 1
77 PDN-JDP-2277 Rack 1
78 PDN-JDP-2278 Screw 1
79 PDN-JDP-2279 Rack Collar 1
80 PDN-JDP-2280 Quill 1
81 PDN-JDP-2281 Table Bracket 1
82 PDN-JDP-2282 Table Handle 1
83 PDN-JDP-2283 Gear Shaft 1
84 PDN-JDP-2284 Set Screw 3
85 PDN-JDP-2285 Hex Head Screw 1
86 PDN-JDP-2286 Crank Sleeve Handle 1
87 PDN-JDP-2287 Tilt Scale 1
88 PDN-JDP-2288 Elevating Worm 1
89 PDN-JDP-2289 Helical Gear 1
90 PDN-JDP-2290 Zero Scale 1
91 PDN-JDP-2291 Table 1
92 PDN-JDP-2292 Hex Nut 2
93 PDN-JDP-2293 Washer 1
94 PDN-JDP-2294 Arm Stud 1
95 PDN-JDP-2295 Washer 1
96 PDN-JDP-2296 Arm Stud 1
97 PDN-JDP-2297 Bolt Hex Head 3
98 PDN-JDP-2298 Spring Washer 3
99 PDN-JDP-2299 Flange 1
100 PDN-JDP-22100 Base 1
101 PDN-JDP-22101 Cord for Clamp 1
102 PDN-JDP-22102 Cord Protect 1
103 PDN-JDP-22103 Head 1
Ordering Replacement Parts
Replacement parts may be ordered from your local distributor or directly from SureWerx.
When ordering replacement parts always provide the following information:
1. The model number and serial number of the machine.
2. The part number.
3. The part name.
4. The desired quantity of the part.
22" 1-1/2 HP 12 Speed Drill Press
