Surna 250 PPD - Page 13

B
1
reifidimuheD anruS1
2
Do not block intake or discharge
3
Do not direct any air into intake or discharge via fans
or vents
4
No conditioned air discharge or circulating fans within
minimum 3 feet (recommended 72 inches) from intake or
discharge of unit
2
4
woleb dna evoba ecnaraelc fo sehcni 21 niMA
B
Min clearance of 24 inches (recommended 72 inches)
from any wall or structure in front of intake or discharge
A
FLOW FLOW
3
WOLFWOLF
REQUIRED UNIT CLEARANCES
Figure 3- Required minimum clearances for Surna dehumidifier
A
Minimum 12 inches (30.5 cm) of clearance above and below
B
Minimum clearance of 24 inches (61 cm) (recommended 72
inches (182.8 cm)) from any wall or structure in front of intake or
discharge
1
Surna dehumidifier
2
Do not block intake or disharge
3
Do not direct any air into intake or discharge via fans or vents
4
No conditioned air discharge or circulating fans within
minimum 36 (91.5 cm) inches (recommended 72 inches (182.8
cm)) from intake or discharge of unit
13
