AERIAL TOWER OPERATION
RATED CAPACITIES:
65’ & 75’ Aerials (built prior to August 18, 2006)
The rated capacity of the 65’ and 75’ aerials is 500 lbs. with or without water in
the waterway, in any position of operation.
70’ Platforms (SP70) (built prior to August 18, 2006)
The rated capacity of the 70’ aerial platform is 500 lbs. with or water in the
waterway, 750 lbs. without water in the waterway, in any position of operation.
75’ Aerials(SA75) and 70’ Platforms (SP70) (built after to August 18, 2006)
The rated capacity of the 70’ aerial platform and 75’ box boom is 750 lbs. with
water in the waterway, 1000 lbs. without water in the waterway, in any position
of operation.
75’ Aerials(SL75)
The rated capacity of the 75’ aerial ladder is 750 lbs. with water in the waterway,
1000 lbs. without water in the waterway, in any position of operation.
Do not exceed the rated capacities!
CAB SET-UP FOR AERIAL OPERATION
1. Spot the rig about 20 feet from the building when possible.
2. Set the parking brake and place the transmission in neutral.
