9-42

INSPECTION AND MAINTENANCE

66J21-03E

Parking/Turn signal light

64J163

Trust this replacement job to your dealer as

the front grille and the headlight housing

must be removed for this job.

Rear combination light

64J164

License plate light

75F087

Door illumination light

64J165

Luggage compartment light

64J166
