14-3
SPECIFICATIONS
66J21-03E
ITEM: Wheel
Tire size, front and rear P225/70R16, P225/65R17
Tire pressure For the specified tire pressure, see the Tire Information Label located
on the driver’s door lock pillar.
ITEM: Steering
Toe-in front 0 ± 2 mm (0 ± 0.08 in.)
rear 6 ± 2 mm (0.24 ± 0.08 in.)
Camber angle front 0° 00’
rear –1° 15’ ± 30’
Caster angle front 2° 30’
ITEM: Capacities (approx.)
Coolant 8.2 L (17.3 US pt)
Fuel tank 66 L (17.4 US gal)
Engine oil (replaced with filter) 4.8 L (10.1 US pt)
Transmission oil M/T 1.9 L (4.0 US pt)
A/T 2.5 L (5.2 US pt) (when drained)
Differential gear oil front 0.95 L (2.0 US pt)
rear
2WD 0.9 L (1.9 US pt)
4WD 0.8 L (1.7 US pt)
Transfer gear box oil with a transfer switch 1.5 L (3.2 US pt)
without a transfer switch 1.6 L (3.4 US pt)
Extension case oil 0.47 L (1.0 US pt)
