Suzuki CELERIO Series - Fuel Filler Cap

5-1
OTHER CONTROLS AND EQUIPMENT
84MM6-01E
Fuel Filler Cap
76MH0A064
62J058
The fuel filler cap is located on the left rear
side of the vehicle. The fuel filler door can
be unlocked by pulling up the opener lever
located on the outboard side of the driver’s
seat and locked by simply closing the door.
68KN048
To remove the fuel filler cap:
1) Open the fuel filler door.
2) Remove the cap by turning it counter-
clockwise.
76MH0A065
NOTE:
If the cap holder (1) is equipped with the
fuel filler door, hold the fuel filler cap when
refueling.
To reinstall the fuel filler cap:
1) Turn the cap clockwise until you hear
several clicks.
2) Close the fuel filler door.
EXAMPLE
EXAMPLE
CAUTION
Remove the fuel filler cap slowly. The
fuel may be under pressure and may
spray out, causing injury.
Open
Close
EXAMPLE
WARNING
Fuel is extremely flammable. Do not
smoke when refueling, and make
sure there are no open flames or
sparks in the area.
(1)
EXAMPLE
