3-16 ENGINE CONTROL
REMOVAL / INSTALLATION
FLYWHEEL / BATTERY CHARGE & POWER SOURCE COIL / CKP SENSOR
1 Flywheel bolt
2 Washer
3 Key
4 Flywheel
5 CKP sensor
6 Screw
7 Battery charge &
Power source coil
8 Bolt
1
2
3
4
5
5
6
7
8
! 190 N
.
m
(19.0 kg-m, 137.5 lb-ft)
P
6
NOTE:
Clean flywheel and crankshaft mating
surfaces with cleaning solvent.
Crankshaft
