89
FUSE
1. If equipped with Keyless Start System:
Turn the Keyless Start System OFF.
If not equipped with Keyless Start System:
Turn the ignition key to the “off” position.
2. Remove the motor cover.
3. Remove the fuse box cover and pull off the
fuse.
NOTE:
Use the fuse puller at the back of fuse box
cover, when the fuse is pulled off and installed.
Fuse box coverFuse box coverFuse box cover
4. Remove the sub battery cable fuse.
5. Inspect the fuse and replace with new fuse if
needed.
NOTE:
If a fuse is blown, try to determine the root
cause and correct it.
If the cause is not corrected, the fuse may be
blown again.
V
WARNING
If you replace a blown fuse with a fuse having
a different amperage rating or with a substi-
tute such as aluminum foil or a wire, extensive
electrical system damage and a fire may
result.
Always replace a blown fuse with a fuse of the
same type and rating.
Sub battery cable
fuse case
Normal fuse
Main fuse (60 A)/
Load fuse (60 A)
Blown fuse
Normal fuse
Blade type fuse
Blown fuse
