87
NOTE:
Before applying grease through the steering
bracket grease nipple, lock the motor in the fully
tilted up position.
Use a hand operated grease gun and follow the
steps below when servicing the grease nipple
A on the engine holder.
1. Turn the engine off and allow it to cool.
2. Remove the motor cover.
3. Remove the rear panel bolts and rear panel
1.
Engine holder
Marine-grade
water resistant
grease
(Grease Gun)
4. DF300B/325A/350A:
Remove the PTT cables from the clamp 2.
DF300BMD/350AMD:
Remove the PTT cable clamp 2 from the
starboard side cover 3.
5. Remove the side cover bolts and starboard
side cover 3.
6. Turn the boat handle to the left so that the
outboard motor’s rudder angle becomes the
largest.
To Next Page
