TILT LIMITER CAM
(DF300B/325A/350A)
If the outboard motor contacts the motor well of
the boat while tilting, adjust the tilt limiter cam to
limit maximum tilt position.
1. Place the motor in the normal running posi-
tion.
2. Rotate the tilt limiter cam:
To reduce the amount of tilt, move the tab A
of cam upward.
To increase the amount of tilt, move the tab
A of cam downward.
3. To check your adjustment, tilt the motor fully
up to check for motor contact.
Adjust further if necessary.
Return the motor to the normal running posi-
tion for each adjustment, and repeat your
check after each adjustment.
V
WARNING
Adjusting the tilt limiter cam will not prevent
the outboard motor from tilting fully up and
contacting the motor well if the motor’s lower
unit hits an object at high speed. Such tilting
could damage your motor and boat and injure
boat occupants.
Keep all occupants away from the motor when
operating at high speed.
SETTING OF TILT UPPER LIMIT POSITION
(DF300BMD/350AMD)
If the outboard motor contacts the motor well of
the boat during full tilt up operation, the upper
limit setting should be reset.
Perform this set-up after the current position
setting has been canceled, as explained in the
following procedure.
CANCELING THE TILT UPPER POSITION
LIMIT SETTING
1. If equipped with Keyless Start System:
Press and hold the engine switch 1 for more
than two seconds to turn on the power.
If not equipped with Keyless Start System:
Turn the ignition key to the “ON” position.
2. Pull out the emergency stop switch lock
plate 2.
OFF
ON
START
