7-24 CHASSIS
FORK SPRING
• Install the fork spring

1 into the front fork.
• Install the washer

2 and spacer

3.
NOTE:
The smaller spring pitch end

A
must face downward.
• Apply fork oil lightly to the O-ring.
#
• Install the spring adjuster to the front fork cap bolt.
• Apply fork oil lightly to the O-ring.
#
• Tighten the front fork cap bolt temporarily.
• Set the front fork to the front fork lower bracket temporarily by
tightening the lower clamp bolts.
Use a new O-ring to prevent oil leakage.
Use a new O-ring to prevent oil leakage.
