THROTTLE VALVE SYNCHRONIZATION

USE OF SDS TOOL

Check and adjust the throttle valve synchronization between two

cylinders.

Step 1

• Lift and support the fuel tank. (!DL650K4 5-7)

• Remove the rubber caps 1 from each vacuum nipple on the

throttle body.

• Connect the vacuum tester hoses 2 to each vacuum nipple.

Step 2

• Connect a tachometer.

• Set up the SDS tool.

• Click “Data monitor”.

• Warm up the engine (Water temp. more than 80 °C (176 °F)).

DL650K7/AK7 (’07-MODEL) 13-61
