Suzuki DR200SE - Page 258

– 8 –
BRAKE + WHEEL Unit: mm (in)
ITEM STANDARD LIMIT
Brake lever play 0.1 – 0.3
(0.004 – 0.010)
—
Rear brake pedal free travel 20 – 30
(0.8 – 1.2)
—
Rear brake pedal height 2.5
(0.10)
—
Brake drum I.D.
Rear —
130.7
(5.15)
Brake lining thickness
Rear —
1.5
(0.06)
Brake disc thickness
Front
3.5 ± 0.2
(0.138 ± 0.008)
3.0
(0.12)
Brake disc runout
Front —
0.30
(0.012)
Master cylinder bore
Front
12.700 – 12.743
(0.5000 – 0.5017)
—
Master cylinder piston diam.
Front
12.657 – 12.684
(0.4983 – 0.4994)
—
Brake caliper cylinder bore
Front
33.960 – 34.010
(1.3370 – 1.3390)
—
Brake caliper piston diam.
Front
33.878 – 33.928
(1.3338 – 1.3357)
—
Wheel rim runout
Axial —
2.0
(0.08)
Radial —
2.0
(0.08)
Wheel axle runout
Front —
0.25
(0.010)
Rear —
0.25
(0.010)
Wheel rim size Front J21 × 1.60 —
Rear J18 × 2.15 —
Tire size Front 70/100-21 M/C 44P —
Rear 100/90-18 M/C 56P —
Tire tread depth
Front —
3.0
(0.12)
Rear —
3.0
(0.12)
12- 8 DR200SEK7/K8 (’07&’08-MODEL)
