6-10 ELECTRICAL SYSTEM
TROUBLESHOOTING
, noi t isop NO si hct iws noi t ingi : kcehC *
. degrahcsid ton s i yret taB :
eht erofeb nwolb ton s i esuF :
.sisongaid
Starter motor will not
Clicks
No click
Run
Not run
Not voltage
Voltage measured
Check the starter relay.
Incorrect
Starter motor runs, but does not start engine.
Incorrect
Correct
Others
Engine does not turnThough
starter motor runs.
Check Whether to hear the click
noise from the starter relay when
the starter button is pushed.
Measure he starter relay voltage at
the starter relay connectors
(between Y/B + and B/W - when
the starter button is pushed.
Check the CDI unit, ignition coil
and generator, (Refer to opages
6-15 and 16)
•Faulty starter motor
•Faulty starter relay
•Loose or disconnected starter motor
lead wire
•Faulty ignition switch
•Faulty starter button
•Poor contact of connector
•Open circuit in wiring harness
•Faulty starter relay
•Faulty CDI unit
•Faulty ignition coil
•Faulty generator
•Open circuit in wiring harness
•Poor contact of connector
•Faulty starter clutch.
Check whether to run the starter
motor when connect the starter
motor terminal to the battery +
terminal directly. (Do not use
thin wire, because a large
amount of current flows.
To Next Page
