YH4

GRAND

VITARA

1. Ears

1. Air flow

1B-38 AIR CONDITIONING (OPTIONAL)

CLEAN

Blow off dust by compressed air from air outlet side of the filter ele-

ment.

INSTALLATION

Reverse removal procedure for installation noting the followings:

 Install filter into cooling unit directing arrow mark on its end face

to heater unit.

 Enable air bag system after installation. Refer to “ENABLING AIR

BAG SYSTEM” in Section 10B.
