YH4
GRAND
VITARA
1. Front differential housing
2. Rear axle
housing
When using floor jack:
Front
Rear
1. Safety stands
0A-20 GENERAL INFORMATION
In raising front or rear vehicle end off the floor by jacking, be sure
to put the jack against the center portion of the front suspension
frame or rear axle housing.
WARNING:
Never apply jack against suspension parts (i.e., stabilizer,
etc.) or vehicle floor, or it may get deformed.
If the vehicle to be jacked up only at the front or rear end,
be sure to block the wheels on ground in order to ensure
safety.
After the vehicle is jacked up, be sure to support it on
stands. It is extremely dangerous to do any work on the
vehicle raised on jack alone.
To perform service with either front or rear vehicle end jacked up,
be sure to place safety stands under chassis frame so that body is
securely supported. And then check to ensure that chassis frame
does not slide on safety stands and the vehicle is held stable for
safety’s sake.
