INSPECTION AND MAINTENANCE
57RK0-14E
*1: Models with LED headlights
*2: Models with CVT
The main fuse, primary fuses and some of
the individual fuses are located in the
engine compartment. If the main fuse
blows, no electrical component will func-
tion. If a primary fuse blows, no electrical
component in the corresponding load
group will function. When replacing the
main fuse, a primary fuse or an individual
fuse, use a genuine SUZUKI replacement
parts or equivalent for individual fuses.
To remove a fuse, use the fuse puller pro-
vided in the fuse box. The amperage of
each fuse is shown in the back of the fuse
box cover.
MAIN FUSE / PRIMARY FUSE
(1)
120 A
FL1
(2)
100 A
FL2
(3)
80 A
FL3
(4)
100 A
FL4
(5)
50 A
FL5
(6)
30 A
Starting motor
(7)
30 A
Blower fan
(8)
40 A
Battery
*1
(9)
40 A
ABS motor
(10)
40 A
Ignition switch
(11)
30 A
B/U
(12)
30 A
IDLE STOP CONT
(13) – Blank
(14) – Blank
(15)
25 A
ABS control module
(16)
15 A
Headlight (Left)
(17)
15 A
Headlight (Right)
(18)
30 A
DCDC
(19)
30 A
Radiator fan
(20) – Blank
(21)
60 A
Power steering
(22) – Blank
(23) – Blank
(24)
20 A
Front fog light
(25)
10 A
Air compressor
(26)
50 A
Ignition switch 2
(27) – Blank
(28)
15 A
FI
*2
(29) – Blank
(30)
15 A
CVT CON
*2
(31)
15 A
T/M PUMP
*2
(32)
5 A
Starting Signal
(33) – Blank
(34) – Blank
(35)
25 A
Headlight high
*1
(36)
15 A
Headlight high (Right)
*1
(37)
15 A
Headlight high (Left)
*1
To Next Page
