7-30
INSPECTION AND MAINTENANCE
57RK0-14E
Fuses
Your vehicle has three types of fuses, as
described below:
Main fuse
The main fuse takes current directly from
the lead-acid battery.
Primary fuses
These fuses are between the main fuse
and individual fuses, and are for electrical
load groups.
Individual fuses
These fuses are for individual electrical cir-
cuits.
To remove a fuse, use the fuse puller pro-
vided in the fuse box cover.
63J095
Fuses in engine compartment
52RM70310
(1) Main fuse box
(2) Relay box
(3) Sub relay box (if equipped)
Main fuse box
52RS70020
Relay box
52RM70050
Sub relay box (if equipped)
52RM70060
EXAMPLE
(1)
(2)
(3)
EXAMPLE
(5)
(3)
(4)
(2)
(1)
(6)
(11)
(12)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(23)
(24)
(25)
(26)
(27)
(28)
(29)
(22)
(7)
(8)
(9)
(10)
(30) (31) (32) (33)
(34)
(35)
(36)
(37)
