6-35
3. If the extension line is beyond the range
as shown in the Fig. B have the brake
shoe assembly replaced by your Suzuki
dealer to ensure safe operation.
REAR BRAKE ADJUSTMENT
WARNING
Riding with worn brake shoes will
reduce braking performance and will
increase your chance of having an acci-
dent.
Inspect brake shoe wear before each
use. Ask your SUZUKI dealer to replace
brake shoes if the shoes are worn to the
limit.
WARNING
Too much play in the rear brake lever can
cause poor braking performance and
may lead to an accident. Too little play
may force brake shoes to rub against the
drum at all times, causing damage to the
shoes and the drum.
Follow the steps in this section to adjust
the rear brake lever properly.
