Suzuki V-Storm DL650A User Manual

3-19
GEARSHIFT LEVER
This motorcycle has a 6-speed
transmission which operates as
shown. To shift properly, squeeze
the clutch lever and close the
throttle at the same time you
operate the gearshift lever. Lift the
gearshift lever to upshift and
depress the lever to downshift.
Neutral is located between 1st
and 2nd gear. When neutral is
desired, depress or lift the lever
halfway between 1st and 2nd
gear.
NOTE: When the transmission is
in neutral the green indicator light
on the instrument panel will be lit.
However, even though the light is
illuminated, cautiously and slowly
release the clutch lever to make
sure that the transmission is posi-
tively in neutral.
Reduce the motorcycle speed
before down-shifting. When down-
shifting, the engine speed should
be increased before the clutch is
engaged. This will prevent unnec-
essary wear on the drive train
components and the rear tire.
REAR BRAKE PEDAL
Pressing the rear brake pedal will
apply the rear brake. The brake
light will come on when the rear
brake is operated.

Suzuki V-Storm DL650A Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 90-degree V-twin
Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.2:1
Fuel System	Fuel injection
Starter	Electric
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Height	1, 405 mm (55.3 in)
Seat Height	835 mm (32.9 in)
Fuel Capacity	20.0 L (5.3 US gal)
Torque	47 lb-ft (63.7 Nm) @ 6, 500 rpm
Rear Brakes	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Length	2, 290 mm
Wet Weight	216 kg (476 lbs)
