Suzuki V-Storm DL650A User Manual

7-5
TOOLS
A tool kit is provided with your
motorcycle. It is located under the
seat.
FUEL TANK LIFT
1. Place the motorcycle on the
side stand.
2. Remove the seat.
3. Remove the bolt 1 and hooks
2. Remove the covers.
4. Remove the fasteners 3 and
bolts 4.

Suzuki V-Storm DL650A Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 90-degree V-twin
Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.2:1
Fuel System	Fuel injection
Starter	Electric
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Height	1, 405 mm (55.3 in)
Seat Height	835 mm (32.9 in)
Fuel Capacity	20.0 L (5.3 US gal)
Torque	47 lb-ft (63.7 Nm) @ 6, 500 rpm
Rear Brakes	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Length	2, 290 mm
Wet Weight	216 kg (476 lbs)
