Suzuki V-Storm DL650A User Manual

7-14
6. Pull off the spark plug cap.
7. Remove the spark plugs with a
spark plug wrench.
NOTE: Be careful not to damage
the radiator fins.
Rear Side
1. Lift the fuel tank by referring to
the FUEL TANK LIFT section.
2. Remove the spark plugs with a
spark plug wrench.
NOTE: Pry up the spark plug cap
with a screwdriver or a bar if it is
hard to remove by hand. Do not
pull the spark plug cord.
WARNING
A hot radiator and hot engine
can burn you.
Wait until the radiator and
engine are cool enough to
touch with bare hands before
starting this work.
CAUTION
Dirt can damage your engine if
it enters an open spark plug
hole.
Cover the spark plug hole
whenever spark plug is
removed.

Suzuki V-Storm DL650A Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 90-degree V-twin
Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.2:1
Fuel System	Fuel injection
Starter	Electric
Lubrication	Wet sump
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Height	1, 405 mm (55.3 in)
Seat Height	835 mm (32.9 in)
Fuel Capacity	20.0 L (5.3 US gal)
Torque	47 lb-ft (63.7 Nm) @ 6, 500 rpm
Rear Brakes	Single disc
Front Tire	110/80 R19
Rear Tire	150/70 R17
Length	2, 290 mm
Wet Weight	216 kg (476 lbs)
