Suzuki V-STROM 800DE User Manual

2-115
NOTE:
• Adjust by aligning the protuberances on
the lever with the indentations on the
adjuster.
• The adjuster is set to the 3rd position at
the factory.
REAR BRAKE PEDAL
DESCRIPTION
Stepping on the rear brake pedal 1 applies
the rear brake. The brake light comes on at
the same time.
The figure shows V-STROM 800DE.
If necessary, see:
• REAR BRAKE PEDAL ADJUSTMENT
( 3-53)
• REAR BRAKE LIGHT SWITCH
( 3-54)
 WARNING
Adjusting the brake lever position while
riding may result in a crash.
Adjust the brake lever position only
while stopped.

Suzuki V-STROM 800DE Specifications

General

Displacement	776 cc
Bore x Stroke	84.0 mm x 70.0 mm
Compression Ratio	12.8:1
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brakes	Disc
Fuel Tank Capacity	20.0 L (5.3 US gal)
Curb Weight	230 kg (507 lbs)
Starter	Electric
Final Drive	Chain
Engine Type	4-stroke, liquid-cooled, DOHC, parallel twin
Front Brakes	Dual disc
Front Tire	90/90-21
Rear Tire	150/70R17M/C 69H
Seat Height	855 mm (33.7 in)
Maximum Power	62 kW (84 PS) / 8, 500 rpm
Maximum Torque	78 Nm @ 6, 800 rpm
Width	975 mm (38.4 in)
Height	1, 310 mm (51.6 in)
Wheelbase	1, 570 mm (61.8 in)
Ground Clearance	220 mm (8.7 in.)
Length	2, 345 mm (92.3 in.)
