8
Such washing machine is designed for home appliances, please
do not install it on ship,traveling truck or plane.
Please turn off the stopcock if long time out of use.
(e.g vacation)
Please remove plug and cancel door lock function to avoid child
locking himself/herself inside.
Packing materials(e.g film, foam) could harm child's safety and
cause asphyxia! Attention: MAKE ALL PACKING MATERIEALS
OUT OF CHILD REACH.
Install drain-pipe
Please fix the drain-pipe by a lifting rope.
For the sake of lightening damage of leak towards ground, please
place the drain-pipe correctly.
In order to avoid siphon , the height of drain-pipe should between
(0.85m-1.25m),moreover, the terminal of drain-pipe should not be
placed in water.
If the drain-pipe is too long, please do not force to insert it into
washing machine, which would cause abnormal noise.
(Please check sketch map next page)
Horizontal Adjustment
To avoid noise and vibrate by adjusting washing machine level.
place it at the room corner preferably.
If ground not level, please adjust alignment
pins.( Do not put wood pieces or something
like), please make sure four alignment pins
touch ground tightly, and machine level
completely.
the instruction of installation of pipe
Ma
x
. 1
2
5cm
M
in
.
8
5c
m
Ma
x
. 1
2
5c
m
M
in
.85
c
m
Wash tub
pipe holder
wire harness
