Svan SVL815IT - Built-In Installation

Appendix
Self-tapping
screws(ST4*12)
Self-tapping
screws(M5*12)
Hinges
Counter magnet Spacer
Fixed position
paper
Tool
Screw driver
Automatic driver Ruler Pencil
Built-in installation
Install Steps
Overview
1
8
2
5
mm
600mm
54
0m
m
595mm
152.5mm
580mm
825mm
Preparation and assembly of the door
The door is open from right to leftThe door is open from left to right
10
33
