6. DESCRIPTION OF THE CONSTRUCTION
a Racing wheel
b Rubber coating
c Keys 1, 4
d Paddle shifters
e Ventilation grids
f Key panel
g Braking indication
h Keys 2, 3
i Lever for changing gears
j Accelerating indication
k Rubber suction
caps
l Keys 7–12
m D-Pad
n Keys 9–10
o MODE button
p ON/OFF MODE
indication
q Sensitivity control
r Foot pedal port
s Headlights
t USB Cable
u Brake pedal
v Acceleration pedal
w Foldable stand for feet
