User Manual
PS-215
Fig. 2. Connection diagram
Note. At the subsequent inclusion of both speakers, they will be connected
automatically.
The use in the wired mode (AUX)
•Speaker system can be used as an external device for amplifying any audio source with
a 3.5 mm output mini-jack. To do this, connect a cable 3.5 mini-jack – 3.5 mini-jack to the
audio output AUX h.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency range, Hz 100-20000
Output power (RMS), W 12 (2 × 6)
Membrane, mm Ø 45
Battery capacity, mA*h 2400
Power supply
USB / ⎓ 5 V
Weight, g 720
Dimensions, mm 85 × 93 × 208
Notes:
• Technical specications given in this table are supplemental information and
cannot give occasion to claims.
• Technical specications and package contents are subject to change without
notice due to the improvement of SVEN production.
USB to USB Type C power cable
