2.3 Swagger 2 Diagram
1. Handles
2. Display
3. Headlight Power Button
4. Headlight
5. Handlebar Stem
6. Suspension
7. Motorized Front Wheel
8. Folding Latch
9. Kickstand
10. Deck
11. Footbrake
12. Rear Passive Wheel
13. Reflector
14. Handbrake
15. Charging Port
16. Throttle
14
15
16
2
1
1
2
12
13
9
6
8
4
3
5
11
10
7
