Here are explanations for the various connections and
lights on the NVR -
1) Power - This is where you connect the power adapter.
2) Audio Out - For connecting speakers.
3) VGA (optional) - If you have a digital TV or monitor with
a VGA connection, connect this to an available input.
4) HDMI - Connect this to your digital TV with a HDMI input
(HDMI cable included).
5) LAN - Connect this to your home network so your NVR
can connect to the Internet.
6 & 7) USB - Connect the supplied mouse here. Also able
to connect a Flash Drive to update the firmware.
8) Wi-Fi Input - The supplied Wi-Fi antenna connects
here. The Wi-Fi antenna communicates with the supplied
cameras as well as your Wi-Fi network.
9) LAN LED - This will flash when there is network activity.
10) HDD LED - This will flash when the hard drive is
working.
11) Power LED - This light will turn on when the NVR has
power.
