Product Description
17
Fuel inlet closure (C)
18

19
Choke control lever (E)
20
Spark-plug connector
21
Starter cord (F)
22
Throttle on engine
23
Engine start/stop button (D)
24
Mowing height locking screw
27
Cylinder cable screw counternut
28
Cylinder cable screw
29
Drive cable screw counternut
30
Drive cable screw
31
Cylinder belt
32
Drive belt
17
18
19 20 21 22
23
24
(E) (F)
(D)
(C)
27
28 29
30
31
32
