14 User Manual
Maintenance
Cleaning
Filter Change
Adjusting
a cloth. Never use pressure washers, their use can void the warranty.
combing, brushing, and mowing dry lawns.
18
A quality lawn depends on properly adjusted mowing blades. Adjust every time you notice the machine is not mowing
well. Perform a preventive check of adjustment before each mowing. (For better illustration, see the video manual at
www.swardman.com.)
Adjust as follows (shown in the paragraph - Checking the Cylinder Adjustment (page 10)):
1. Stop the machine engine
2. Disconnect the spark plug
3. Let the engine cool down
4. Put on protective gloves
5.
6. Close the fuel cock
17
7. Tilt the machine onto the handlebars
8. Take a strip of plain paper and the 8 mm wrench
9. Kneel down in front of the mower
10. Gripping the paper strip in one hand, simulate a blade of grass and bring it perpendicularly before the bed-knife
11. Turn the cylinder with your other hand so that the paper is cut - be very careful - the mowing blades can cause
painful injuries even at a low speed
12.
point, the machine is adjusted correctly.
13. If the paper has not been cut or the cut has not been smooth, it is necessary to draw the bed-knife up towards
the cylinder.
14. To do so, use the wrench on the blade adjustment nut
25
and slightly turn the nut clockwise.
15. Repeat the check using another piece of paper. Repeat this process until the cylinder cuts perfectly over the total
width.
16. If the mowing system has been used for a prolonged period (depending on the mowing intensity and dimensions
no longer helps to achieve a smooth cut, the mowing blades must be sharpened. How to have the mowing blades
sharpened, visit the Swardman e-shop in the Service Section.
17. You can lubricate the cylinder blade with organic oil after each mowing to protect the blade against corrosion and
reduce any noise and friction at the same time.
