9 User Manual
Technical Data
Cylinder lawn mower Edwin 45 Edwin 55
Order number E45S E55S
Cylinder displacement (cm) 99 99
Fuel tank capacity (l) 1.6 1.6
Fuel Unleaded petrol w. octane rating 98 or higher
Oil tank capacity (l) 0.46 0.46
Oil type SAE 30 SAE 30
Rated power 1.9 kW (2.6 HP) 1.9 kW (2.6 HP)
Maximum operating speed (kmph
-1
) 6 6
Maximum engine operating speed (rpm
-1
) 2800 2800
Spark plug NGK BR6HS NGK BR6HS
Cutting width (cm) 45 (18”) 55 (22”)
Mowing height (mm) 5 – 45 5 – 45
Number of cuts per meter (5-blade cylinder) 60 60
Grass box volume (l) 40 50
Weight (kg) 52 59
Maximum overall width (cm) 54 64
Declared sound pressure level A
on the operator‘s side
1
L
pAd
(dB)
77 + 1 79 + 2
Guaranteed sound power level A L
WA,G
(dB) 92 94
Declared aggregate value of acceleration of
vibrations transferred to the operator‘s hand/
a
hvd
(mps
-2
)
3.1 + 1.6 2.9 + 1.5
Serial number
² measured in accordance with the Government Decree No. 9/2002 Coll., or the Directive 2000/14/ES
