** Removing the glove compartment:
1 -> Remove the side panel, using a fishbone tool OR open glove compartment first then pull on the side of the panel (1)
and pull out (2).
2 -> Remove the protective step-in cover, only pull up at the front side! (back side facing part will only allow pulling for-
ward!)
1 -> Pull the rubber away, at least so far that the plastic cover (right image) is free
2 -> Remove the side cover by pulling up and towards the back of the car to release the clips, then move the panel in-
wards to remove it.
1 -> Remove the 2 torx (size 20) screws and remove the panel.
2 -> Remove the 2 torx (size 20) screws.
