1 -> Open the glove compartment and remove the torx screws (size 20) and the 2 bolts (size 8)
2 -> Take the glove compartment out by pulling towards the back of the car and tilting it a bit up and down.
** In case a front camera is mounted, access to the engine bay can be found BEHIND the CEM or BELOW the CEM.
The CEM is the Central Electronics Module, to be found behind the glove compartment. The CEM also holds the fuses.
Behind the CEM : dry area below the windscreen wipers in the engine bay. Rather easy to reach without lifting the car.
Below the CEM : wet area in engine bay next to exhaust pipe (passenger side) directly accessing the cabin. Car needs to be
lifted to reach that point in the engine bay.
Dry area (reachable without lifting the car)
Wet area (car needs to be lifted to reach the rubber in the engine bay)
