CE300AF
Page 12 of 15
15 Trouble Shooting
Problem Solution
15.A Material Feeding Stops
Too large of a gap exists
between the feed rolls
for the material being
fed
Adjust the set screw on the top of the feedworks to close the
feedroll gap
chain
Inspect chain for adequate tension or if it is broken
Banding is twisted or
bent
Straighten out bent portion or remove it entirely
Worn feedrolls Replace the worn feedrolls
15.B Machine Fails to Cut
Material is too large for
machine
Run appropriately sized material into the machine
Poor knife gap Inspect knife gap to ensure it is within tolerance
Knife edges are dull Rotate or replace knives
15.C Machine will not start/stop running
Motor protection tripped Reset motor
Broken drive belt Replace belt
Failed electrical service Check circuit power
Switch failure Replace switch
