20170724 We reserve the right to alter specifications.
GLOBAL
3
3.1 Analogue Input (RO): A1
Object
Instance
Object Name Min/Max
1 K2 Analog input 0-10,0 [V]
Analog input on K2 contact
2 K3 Analog input 0-10,0 [V]
Analog input on K3 contact
3 T° out -99,9-99,9 [°C]
Outside temperature measured on T1 sensor (-999=open, +999=short circuit)
4 T° extract -99,9-99,9 [°C]
Extract temperature measured on T2 sensor (-999=open, +999=short circuit)
5 T° exhaust -99,9-99,9 [°C]
Exhaust temperature measured on T3 sensor (-999=open, +999=short circuit)
6 T° antifrost internal hydraulic postheater -99,9-99,9 [°C]
Temperature for the antifrost protection of the hydraulic postheater inside the unit meas-
ured on T4 sensor (-999=open, +999=short)
7 T° supply -99,9-99,9 [°C]
Supply temperature measured on T5 sensor (-999=open, +999=short)
8 T° antifrost external hydraulic postheater -99,9-99,9 [°C]
Temperature for the antifrost protection of the hydraulic postheater external to the unit
measured on T7 sensor (-999=open, +999=short)
9 T° antifrost external hydraulic postcooler -99,9-99,9 [°C]
Temperature for the antifrost protection of the hydraulic postcooler external to the unit
measured on T8 sensor (-999=open, +999=short)
