Smart Extension Temperature module
Sensor
T6 T7
T8 T9
Smart unit
SET2 SET1
DI
max 50 VDC
NC NC NC
1 2 3 4 5 6 7 8 9 10 11 12
max 250 V / 6 A
Relay 1
4 3 2 1
max 250 V / 6 A
Relay 2
NC
4 3 2 1
AO3AO2AO1
NC
NC NC
SET
11
230 V
7
9 6
3
Important
If the SET module is used for 230 VAC
control, the module must be installed,
according to the electrical safety
directives, in a separate enclosure.
Make sure that the strain relief is
arranged for the connections according to
the electrical safety directives.
!
!
1: CASA Smart ventilation unit* | 3: Outdoor air temperature sensor
| 6: Solenoid valve* | 7: Circulation water pump* | 9: Power source
24 VDC* |
*) Not included in the delivery.
