38
Guide Rail
for Thread
Take-Up Lever
②
Guide rail for thread take-up lever. Clean once a
week.
Movable and fixed blades. Clean once or twice a
week. To clean, remove the needle plate and then
pull the movable blade forward as shown. Clean,
and then reassemble. Take note of the order the
parts are removed so you can replace correctly.
Movable Blade
Fixed
Blade
③
CAUTION
Sun Star is not responsible for machine damages or malfunctions caused by
insufficient or irregular cleaning or oiling.
CAUTION
Turn OFF the main power before inspecting or cleaning of the following parts.
Adjust your cleaning cycle to the environment and conditions of your machine.
