WIRING OF CONNECTING CABLE AND CARAVAN MAINS INLET
Warning: it is essential that connections are made exactly as shown. If terminal markings are not in accordance with the diagram they must be
ignored. If in doubt consult a qualified electrician.
Thelegallengthofthemainsinletcableis25±2metres.Wheninuseitmustbefullyuncoiledandprotectedfromtrafc.
